QTM-500 Quick Thermal Conductivity Meter
CE approved Manufacturer. Complete unit ready for operation, includes:
* Hot Wire method
* Measuring Range 0.023 to 12W/mK
* Standard measuring time of 60 seconds
* Sensor: PD-11 Box Probe with constant heater wire and chromel-alumel thermocouple
* RS-232C 2 channels
* Thermocouple electro-motive force 1 channel
* Power Consumption: 60W
* Main unit: 300W x 475D x 175H mm
* Power AC 100-240V
* Large LCD Display, shows thermal conductivity, measuring temperature, and guiding message for measurement
* Approximately 9 kg
Supplied Parts:
1 PD-11 Box probe
1 Probe constant card
1 Power cord with ground wire
2 Power fuse
3 Reference plate:
R1-2 Clear quartz in box
R2-2 Silicon rubber in box
R3-2 Polyethylene foam in box
1 Cooling plate (aluminum)
1 Brush
3 Operating manual
|
|
|
|
|
|
